Poisson equation using Python for source term specification

Poisson Equation

The Poisson equation is: \[ \begin{equation} - k\; \Delta p = Q \quad \text{in }\Omega \end{equation}\] w.r.t boundary conditions \[ \eqalign{ p(x) = g_D(x) &\quad \text{on }\Gamma_D,\cr k\;{\partial p(x) \over \partial n} = g_N(x) &\quad \text{on }\Gamma_N, }\]

where \(p\) could be the pressure, the subscripts \(D\) and \(N\) denote the Dirichlet- and Neumann-type boundary conditions, \(n\) is the normal vector pointing outside of \(\Omega\), and \(\Gamma = \Gamma_D \cup \Gamma_N\) and \(\Gamma_D \cap \Gamma_N = \emptyset\).

Problem specification and analytical solution

We solve the Poisson equation on a square domain \(\Omega = [0\times 1]^2\) with \(k = 1\) w.r.t. the specific boundary conditions: \[ \eqalign{ p(x,y) = 1 &\quad \text{on } (x=0,y=0) \subset \Gamma_D,\cr p(x,y) = 1 &\quad \text{on } (x=0,y=1) \subset \Gamma_D,\cr p(x,y) = 1 &\quad \text{on } (x=1,y=0) \subset \Gamma_D,\cr p(x,y) = 1 &\quad \text{on } (x=1,y=1) \subset \Gamma_D,\cr }\] and the source term is \[ Q(x,y) = a^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) +b^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) \]

The analytical solution of (1) is \[ p(x,y) = \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right). \] Since \[ \frac{\partial^2 p}{\partial x} (x,y) = - a^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) \] and \[ \frac{\partial^2 p}{\partial y} (x,y) = - b^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) \] it yields \[ \Delta p(x,y) = - a^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) - b^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) \] and \[ Q = - \Delta p(x,y) = a^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right) + b^2 \sin\left(ax - \frac{\pi}{2}\right) \sin\left(by - \frac{\pi}{2}\right). \]

Input files

The project file is square_1e3_poisson_sin_x_sin_y.prj. It describes the process to be solved and the related process variable together with their initial, boundary conditions and source terms. The definition of the source term \(Q\) is in a Python script. The script for setting the source terms is referenced in the project file as follows:

<python_script>sin_x_sin_y_source_term.py</python_script>

In the source term descripition

<source_term>
    <mesh>square_1x1_quad_1e3_entire_domain</mesh>
    <type>Python</type>
    <source_term_object>sinx_siny_source_term</source_term_object>
</source_term>

the domain is specified by the mesh-tag. The function \(Q\) is defined by the Python object sinx_sinx_source_term that is created in the last line of the Python script:

import OpenGeoSys
from math import pi, sin

a = 2.0*pi
b = 2.0*pi

def solution(x, y):
    return - sin(a*x-pi/2.0) * sin(b*y-pi/2.0)

# - laplace(solution) = source term
def laplace_solution(x, y):
    return a*a * sin(a*x-pi/2.0) * sin(b*y-pi/2.0) + b*b * sin(a*x-pi/2.0) * sin(b*y-pi/2.0)

# source term for the benchmark
class SinXSinYSourceTerm(OpenGeoSys.SourceTerm):
    def getFlux(self, t, coords, primary_vars):
        x, y, z = coords
        value = laplace_solution(x,y)
        Jac = [ 0.0 ]
        return (value, Jac)

# instantiate source term object referenced in OpenGeoSys' prj file
sinx_siny_source_term = SinXSinYSourceTerm()

Running simulation

To start the simulation (after successful compilation) run:

$ ogs square_1e3_poisson_sin_x_sin_y.prj

It will produce some output and write the computed result into the square_1e3_volumetricsourceterm_pcs_0_ts_1_t_1.000000.vtu, which can be directly visualized and analysed in paraview for example.

The output on the console will be similar to the following on:

info: This is OpenGeoSys-6 version 6.1.0-1132-g00a6062a2.
info: OGS started on 2018-10-10 09:22:17+0200.

info: ConstantParameter: K
info: ConstantParameter: p0
info: ConstantParameter: pressure_edge_points
info: Initialize processes.
createPythonSourceTerm
info: Solve processes.
info: [time] Output of timestep 0 took 0.000695229 s.
info: === Time stepping at step #1 and time 1 with step size 1
info: [time] Assembly took 0.0100119 s.
info: [time] Applying Dirichlet BCs took 0.000133991 s.
info: ------------------------------------------------------------------
info: *** Eigen solver computation
info: -> solve with CG (precon DIAGONAL)
info:    iteration: 81/10000
info:    residual: 5.974447e-17

info: ------------------------------------------------------------------
info: [time] Linear solver took 0.00145817 s.
info: [time] Iteration #1 took 0.0116439 s.
info: [time] Solving process #0 took 0.011662 s in time step #1
info: [time] Time step #1 took 0.0116858 s.
info: [time] Output of timestep 1 took 0.000671864 s.
info: The whole computation of the time stepping took 1 steps, in which
         the accepted steps are 1, and the rejected steps are 0.

info: [time] Execution took 0.0370049 s.
info: OGS terminated on 2018-10-10 09:22:17+020

Results and evaluation

Comparison of the numerical and analytical solutions

Comparison for higher resolution mesh (\(316 \times 316\) elements)
